Maxhub E6520 V6-E-Series Interactive Smart Board

Best-in-class performance comes easily with the MAXHUB Interactive Flat Panel E2 Series. Combining a pro-grade display with the effortless operation and innovative safety features to protect students’ health, this classroom all-star meets the unique needs of young learners and those who teach them.

• Content comes alive on the E2 Series’ 4K, high-contrast screen. Images, text and handwriting are rendered with astonishing sharpness and professional-grade color accuracy. The flicker-free screen reduces eye strain, and anti-glare glass eliminates distracting reflections.
• TÜV-certified to protect eyes and preserve students’ vision, the E2 Series’ display minimizes visual fatigue by reducing blue light and reflections, eliminating flicker, and automatically adjusting brightness to adapt to the indoor environment.
• Providing a natural writing experience with no learning curve, the E2 Series enables teachers and students alike to write easily, silently and efficiently. Zero Bonding technology | Double nib design, 3mm fine nib | Up to 40 touch points | Less than 40ms writing latency
• Designed to inhibit bacterial reproduction and other risks, the E2 Series features an optional antimicrobial screen, which is specially coated and manufactured with 3mm tempered glass to protect users from accidental injury.
• Count on the E2 Series to keep pace with the rapid flow of ideas in your classroom. Powerful processing performance erases system lag. The gigabit network card speeds through data downloads.
• The high-power speaker reaches every corner of your classroom, boosting engagement and student comprehension. 2x12W output power
• Lose your fear of data loss. The optional one-click switch backup system provides powerful protection from software crashes with the help of a dual system(Android & windows)
• Bringing BYOD convenience and capabilities to the classroom, the E2 Series features an all-in-one Type-C interface for your mobile device.
• Supports audio and display up to 4K@60fps.
• Supports charging up to 65W.
• Laptop internet access via Type-C interface on web-connected the E2 Series displays.

Specification:

Display

• Diagonal Size（inch): 65
• Glass: Anti-glare, Tempered
• Bonding: Zero parallax
• Viewing Angle: 178°(H/V)
• Aspect ratio: 16:9
• Blacklight: DLED
• Resolution: 3840 × 2160
• Contrast Ratio: 1200:1
• Color Depth: 1.07B(10bit)
• Color Gamut（typ.):  72% NTSC
• Color Accuracy: Delta E ≤ 2
• Refresh Rate: 60Hz
• Response time: 8ms
• Brightness（typ.）: 350cd/m²

Interactivity

• Touch Sensor: Infrared（IR）
• Touch Tool: Finger,Gesture,Stylus
• Multitouch Capabilities: Up to 40 touch points（OS dependent）
• Response Time: ≤ 10ms
• Touch Accuracy: ±1.5mm
• Object Recognition Range: ≥ 3mm
• Stylus Type: Passive dual nibs
• Supported Operating System (Touch Return): Windows10 / Windows8 / Windows7 / WindowsXP / Android / Linux / Mac OS X / Chrome OS

Built-in System

• Operating System: Android 11.0
• RAM: 4GB
• ROM: 32GB
• CPU: 2.0GHz quad core ARM A55

• GPU: Mali-G52 MP2

Software

• Screen Share: Yes
• DMS: Yes
• On Board Apps: Browser, Cloud Drive, System Keeper, Note, Palette, Annotate, Timer, Screen Record, Split Screen, etc.

Power

• Power Supply: AC 100~240V 50/60Hz
• Power Consumption（standby）: ≤ 0.5W
• Power Consumption（maximum): 400W（including OPS）

Connectivity

• OPS Slot: Yes, 3840 × 2160 @ 60fps
• OPS Compatible: OPS62A
• Wired: 1000baseT RJ45 × 2
• Wi-Fi: 2.4Ghz, 5Ghz band, 802.11ac/b/g/n/a/ax
• HDMI: HDMI 2.0 In × 3, HDMI Out × 1（Up to 4K @ 60fps）
• Touch: USB Type-B × 2
• Analog: VGA In × 1
• Audio: Audio In × 1, Audio Out × 1, S/PDIF Out × 1
• USB Type-A: USB 3.0 × 4, USB 2.0 × 1
• Multifunction Port: USB Type-C × 1

Accessory

• 3m Power Cord: 1
• 1.4m HDMI Cable: 1
• 5m USB Touch Cable（Type A-B）: 1
• 1.8m USB Type-C Cable: 1
• Remote Control: 1
• Wall Mount: 1
• Stylus: 2
• Wireless Adapter: 1

Physical Specification

• Dimension（W × H × D）: 1488.1 × 896.3 × 88.3mm
• Net Weight: 35.50Kg
• Gross Weight: 45.80Kg

Certificate

• TüV Rheinland Flicker Free: Yes
• TüV Rheinland Low Blue Light: Yes
• SGS Antibacterial: Stylus, Power Button, Protection Glass（optional）
